Custom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy Tags

Custom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy Tags
Custom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy TagsCustom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy TagsCustom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy TagsCustom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy TagsCustom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy Tags
group name
NFC dog tag
Min Order
1000 piece
brand name
DC-NFC Tag Manufacturer
model
2.7*2.9cm NFC dog tag
Nearest port for product export
Yantian Port
Delivery clauses under the trade mode
FOB, CFR, CIF, EXW
Acceptable payment methods
T/T
update time
Sat, 05 Apr 2025 03:11:53 GMT

Paramtents

  • Size 2.7*2.9*0.2cm, 3.8*4.2*0.27cm

  • Material PVC

  • Reading distance 2-5CM

  • storage 144bytes

  • Protocol ISO 14443A

  • Type Passive

  • Animals Dogs, Cats, All kinds of pets

  • Customized support Customized logo

  • Application Animal Management

Packging & Delivery

  • Min Order1000 piece

Briefing

Custom 13.56mhz Waterproof RFID NFC Logo PVC Dog Cat Pet Epoxy Tags

Detailed

2.7*2.9CM NFC dog tag Description
 6Mm FPC NFC TAG
High Quality 2.7*2.9CM NFC dog tag


Application industry:Animal Management



●Characteristic:
2.7*2.9CM High temperature resistant NFC,NTAG 213 chip


2.7*2.9CM NFC dog tag Specification
Features
Contactless transmission of data and supply energy
Operating frequency
13.56 MHz
Data transfer
106 kbit/s
Data integrity
16-bit CRC, parity, bit coding, bit counting
7-byte serial number (cascade level 2 according to ISO/IEC 14443-3).UID ASCII mirror for automatic serialization of NDEF messages..Automatic NFC counter triggered at a reading command.NFC counter ASCII mirror for automatic adding the NFC counter value to the NDEF message.ECC-based originality signatureFast read commandTrue anti-collision
180, 540 or 924 bytes organized in 45, 135 or 231 pages with 4 bytes per page.
144, 504 or 888 bytes freely available user Read/Write area (36, 126 or 222 pages).
4 bytes initialized capability container with one-time programmable access bits.
Field programmable read-only locking function per page for the first 16 pages.
Field programmable read-only locking function above the first 16 pages per double page for NTAG 213 or per 16 pages for NTAG 215 and NTAG 216.
Configurable password protection with an optional limit of unsuccessful attempts.
Anti-tearing support for capability container (CC) and lock bits.
ECC supported originality check.
Data retention time of 10 years.
Write endurance 100,000 cycles.
2.7*2.9CM NFC dog tag Applications
10Mm NFC FPC Small Tag Application
2.7*2.9CM NFC dog tag FAQ
1. How can I get the 2.7*2.9CM NFC dog tag Description Small price?
Please Send your inquiry Details or add our online tool then we can provide you with a quotation for the first time.

2. Can you   offer free samples?
Yes, usually we can offer you free samples
A: For stock samples, we can send you free samples for your test, you pay for the shipping cost.
B: For customized samples, we will charge the reasonable production cost and try to refund you after order confirmed

3. What is your lead time?
Usually, our lead time is 1-7 days for samples and 7-20 days for mass production.

4.  What's your payment method  ?
Our payment method are T/T, Ali Trade Assurance for mass production order; Paypal.

5. How can I Choose the chip?
Check above chips lists or just email with us of the application, we will give the best suggestions.
